Technical specifications.

Interior dimensions

-Length: 13,316 mm

-Width: 2440 mm

-Height: 2,569 mm

-Interior height (up to loading limit): 2,469 mm

External dimensions

-Length: 13 716 mm

-Width: 2 580 mm

-Height: 2,896 mm

Door dimensions

-Width: 2440 mm

-Height: 2,562 mm

Temperature: -25 to 25 ° C

Refrigerant

-R134 A

-R404

-R442 on request

Structure: CORTEN and INOX

Floor

FLAT ALU FLOOR

Management by a Daikin, Thermoking or Carrier console

Storage of up to 33 Euro pallets

Double leaf opening on one of the exterior faces

Doors open at 270 °

Additional information

-Max load: 27 820 kgs

-Weight empty: 6,180 kgs

-Max weight: 34,000 kgs

-Usable interior volume (up to maximum ventilation line): 83.14 m3
